Honeywell 1 Axis Through Hole Hall Effect Sensor 4.5 V 10.5 V, TO-92, 3-Pin | SS495B
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 10 pcs
Mfr. Part No: SS495B
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Honeywell |
| Sensor Type | Hall Effect Sensors |
| Product Type | Hall Effect Sensor |
| Number of Axis | 1 |
| Technology | Hall Effect |
| Mount Type | Through Hole |
| Minimum Supply Voltage | 4.5V |
| Maximum Supply Voltage | 10.5V |
| Package Type | TO-92 |
| Minimum Operating Temperature | -40°C |
| Sensitivity | 3% |
| Maximum Operating Temperature | 150°C |
| Pin Count | 3 |
| Height | 1.7mm |
| Series | SS490 |
| Width | 3 mm |
| Standards/Approvals | No |
| Length | 4.06mm |
| Response Time | 3μs |
| Supply Current | 7mA |
| Automotive Standard | No |
Product Details
The Honeywell SS490 series are small, versatile, linear Hall-effect devices which are operated by the magnetic field from a permanent magnet or an electromagnet. The ratiometric output voltage is set by the supply voltage and varies in proportion to the strength of the magnetic field. The integrated circuitry provides increased temperature stability and sensitivity. It has laser-trimmed, thin film resistor which provide high accuracy (null to ±%, sensitivity up to ±3%) and temperature compensation. It respond to either positive or negative gauss, monitoring either or both magnetic poles. The quad hall sensing element minimizes the effects of mechanical or thermal stress on the output.
Linear output for circuit design flexibility
Uses 7 mA at 5 Vdc for energy efficiency
Single current sinking or current sourcing output
Rail-to-rail operation provides more usable signal for higher accuracy
Temperature-compensated magnetics help provide s
