Honeywell 14CE Series Plunger Limit Switch, 1NC/1NO, IP65, IP66, IP67, IP68, SPDT, Die Cast Zinc Housing, 240V ac ac | 14CE1-3
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 15 pcs
Mfr. Part No: 14CE1-3
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Honeywell |
| Actuator Type | Plunger |
| Pole and Throw Configuration | SPDT |
| Normal State Configuration | 1NC/1NO |
| IP Rating | IP65, IP66, IP67, IP68 |
| Maximum Current | 5A |
| Housing Material | Die Cast Zinc |
| Maximum AC Voltage | 240V ac |
| Connection Type | 1m Cable |
| Series | 14CE |
| Action Type | Snap Action |
| Maximum Operating Temperature | +70°C |
| Minimum Operating Temperature | 0°C |
| Standards Met | CE Certified |
| Mechanical Life | 10000000Cycles |
Product Details
Honeywell Snap-Action Plunger Sensor Switch, 240V AC, 5A – 14CE Series – 14CE1-3
Streamline the quick on-and-off switching of your electrical devices with this plunger sensor switch from Honeywell. Its actuator is fitted with a snap-action mechanism, which rapidly connects the NC (normally closed) and NO (normally open) contacts when triggered for fast switching. As it’s made from zinc, this product is chemical and corrosion-resistant for use in harsh industrial environments. Its SPDT (single pole double throw) configuration makes it a good choice for multi-action performance, such as turning on two different lights when the switch position is changed.
Features & Benefits
• Voltage rating of 240V AC for use in high-energy systems
• Long mechanical lifespan of 10 million cycles for long-lasting performance
• M12 four-pin connector for quick and easy installation
• Long mechanical lifespan of 10 million cycles for long-lasting performance
• M12 four-pin connector for quick and easy installation
Applications
• Control valves
• Factory conveyor belts
• Waste treatment machinery
• Factory conveyor belts
• Waste treatment machinery
Is this plunger limit switch suitable for outdoor installation?
Yes, this plunger limit switch is suitable for outdoor installation thanks to its combined IP65 (ingress protection), IP66, IP67 and IP68 ratings. This means the switch is fully shielded against dust and protected against varying degrees of exposure to moisture.
