Honeywell 3 Axis Through Hole Hall Effect Sensor 4 V 24 V, TO-92, 3-Pin | VG481V1
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: VG481V1
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Honeywell |
| Product Type | Hall Effect Sensor |
| Sensor Type | Hall Effect |
| Number of Axis | 3 |
| Technology | Back Biased Hall-effect |
| Mount Type | Through Hole |
| Magnetic Type | Hall |
| Maximum Frequency Response | 10000Hz |
| Minimum Frequency Response | 0Hz |
| Minimum Supply Voltage | 4V |
| Package Type | TO-92 |
| Maximum Supply Voltage | 24V |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 150°C |
| Pin Count | 3 |
| Height | 3mm |
| Series | VG481V1 |
| Width | 1.52 mm |
| Standards/Approvals | AEC-Q100 (Grade 0) |
| Length | 4.6mm |
| Supply Current | 10mA |
| Automotive Standard | AEC-Q100 Grade 0 |
Product Details
The Honeywell VG481V1 contains a dual peak detecting circuit that is coupled with a hall-effect element to detect the speed of a ferrous gear tooth target wheel. A biasing magnet provides a changing magnetic field as the target wheel moves past the senor IC. It consists of a voltage regulator, clock/oscillator, Hall element, amplifier, internal peak/valley track and hold circuits, comparator, and open collector output stage. The . The sensor IC is protected from abnormal operation at low voltage by a power-on rest circuit. The output circuitry contains short circuit protection.
Back-biased speed sensor IC
Zero-speed capable
Low cost and easy to use
4 V to 24 V supply voltage range
-40°C to 150°C operating temperature range
