Honeywell ABP2DANT150PGSA3XX Piezoresistive Pressure SensorThrough Hole 6 DIP | ABP2DANT150PGSA3XX

Name: Honeywell ABP2DANT150PGSA3XX Piezoresistive Pressure SensorThrough Hole 6 DIP | ABP2DANT150PGSA3XX
SKU: 4115-812
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 12 pcs

Mfr. Part No: ABP2DANT150PGSA3XX

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 4115-812 Categories: Honeywell, Pressure Sensor ICs

Description

Specifications

Attribute	Value
Brand	Honeywell
Product Type	Piezoresistive Pressure Sensor
Maximum Overload Pressure	16bar
Sensor Type	Piezoresistive Pressure Sensor
Mount Type	Through Hole
Package Type	DIP
Pin Count	6
Minimum Supply Voltage	1.8V
Maximum Operating Pressure	1034 kPa
Accuracy	±0.25 %
Maximum Supply Voltage	3.6V
Port Type	Barbed
Maximum Operating Temperature	110°C
Series	ABP
Length	7.3mm
Standards/Approvals	No
Width	6.3 mm
Height	7mm
Minimum Operating Pressure	600Pa
Automotive Standard	No
Minimum Operating Temperature	-40°C

Product Details

The Honeywell Control System’s ABP2 Series are piezoresistive pressure sensors which are state of the art board mount Pressure Sensors with high accuracy and versatility. The areas of applications are Ventilators/portable ventilators, CPAP, blood analysis, blood pressure monitoring HVAC transmitters, life sciences, material handling, pneumatic control and regulation, process gas monitoring and valve positioning/ positioners, etc.

Has wide operating temperature range

Is 24-bit digital I2C or SPI-compatible output

Exhibits long term stability as low as ±0.2 %FSS

Is REACH and RoHS compliant
