Honeywell ABP2DDAN005NDAA5XX Piezoresistive Pressure SensorThrough Hole 6 DIP | ABP2DDAN005NDAA5XX

Name: Honeywell ABP2DDAN005NDAA5XX Piezoresistive Pressure SensorThrough Hole 6 DIP | ABP2DDAN005NDAA5XX
SKU: 7209-622
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 12 pcs

Mfr. Part No: ABP2DDAN005NDAA5XX

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 7209-622 Categories: Honeywell, Pressure Sensor ICs

Description

Specifications

Attribute	Value
Brand	Honeywell
Sensor Type	Piezoresistive Pressure Sensor
Maximum Overload Pressure	206.83kPa
Product Type	Piezoresistive Pressure Sensor
Mount Type	Through Hole
Package Type	DIP
Pin Count	6
Minimum Supply Voltage	1.8V
Maximum Operating Pressure	1.25 kPa
Accuracy	±0.25 %
Port Type	Dual Axial Barbed
Maximum Supply Voltage	3.6V
Maximum Operating Temperature	110°C
Series	ABP
Standards/Approvals	No
Length	7.3mm
Height	7mm
Width	6.3 mm
Minimum Operating Pressure	600Pa
Minimum Operating Temperature	-40°C
Automotive Standard	No

Product Details

The Honeywell ABP2 series are piezo resistive silicon pressure sensors offering a digital output for reading pressure over the specified full scale pressure span and temperature range. This sensor IC have dual axial barbed port and the operating pressure is the ±5 inH20.

Total error band as low as ±1.5 %FSS

Long-term stability as low as ±0.2 %FSS

Wide operating temperature range of -40°C to 110°C

High burst pressures
