Honeywell ABPDRRV001PDSA3 Differential Pressure SensorThrough Hole 6 DIP | ABPDRRV001PDSA3

Name: Honeywell ABPDRRV001PDSA3 Differential Pressure SensorThrough Hole 6 DIP | ABPDRRV001PDSA3
SKU: 3936-302
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 6 pcs

Mfr. Part No: ABPDRRV001PDSA3

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 3936-302 Categories: Honeywell, Pressure Sensor ICs

Description

Specifications

Attribute	Value
Brand	Honeywell
Maximum Overload Pressure	206kPa
Sensor Type	Differential Pressure Sensor
Product Type	Differential Pressure Sensor
Mount Type	Through Hole
Package Type	DIP
Pin Count	6
Minimum Supply Voltage	-0.3V
Maximum Operating Pressure	6.9 kPa
Maximum Supply Voltage	5V
Accuracy	±0.25 %
Port Type	Dual Radial Barbed
Maximum Operating Temperature	85°C
Series	ABP
Standards/Approvals	No
Length	7.3mm
Width	6.3 mm
Height	3.63mm
Minimum Operating Pressure	0psi
Minimum Operating Temperature	-40°C
Automotive Standard	No

Product Details

The Honeywell ABP series 1psi basic board mount pressure sensor is featured with high accuracy. It is a piezo resistive silicon pressure sensors which offers a ratiometric analogy or digital output for reading pressure over the specified full scale pressure span and temperature range.

Measures gage and differential

Liquid media option

Meet IPC/JEDEC J-STD-020D.1

Moisture Sensitivity Level 1 requirements

REACH and RoHS compliant
