Honeywell ABPLLNN015PGST5 Piezoresistive Pressure SensorSurface 0 Leadless SMT | ABPLLNN015PGST5

Name: Honeywell ABPLLNN015PGST5 Piezoresistive Pressure SensorSurface 0 Leadless SMT | ABPLLNN015PGST5
SKU: 2169-622
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 16 pcs

Mfr. Part No: ABPLLNN015PGST5

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 2169-622 Categories: Honeywell, Pressure Sensor ICs

Description

Specifications

Attribute	Value
Brand	Honeywell
Sensor Type	Gauge Pressure Sensor
Product Type	Piezoresistive Pressure Sensor
Maximum Overload Pressure	206kPa
Mount Type	Surface
Package Type	Leadless SMT
Pin Count	0
Minimum Supply Voltage	-0.3V
Maximum Operating Pressure	103 kPa
Port Type	Single Axial Barbless
Accuracy	±0.25 %
Maximum Supply Voltage	5V
Maximum Operating Temperature	85°C
Height	7.23mm
Standards/Approvals	No
Length	7.3mm
Series	ABP
Width	6.3 mm
Minimum Operating Pressure	0psi
Automotive Standard	No
Minimum Operating Temperature	-40°C

Product Details

The Honeywell ABP Series are piezoresistive silicon pressure sensors offering a ratiometric analog or digital output for reading pressure over the specified full scale pressure span and temperature range. They are calibrated and temperature compensated for sensor offset, sensitivity, temperature effects and accuracy errors which include non linearity, repeatability and hysteresis using an on board Application Specific Integrated Circuit that is ASIC.

Measures gauge and differential pressures

High burst pressures

REACH and RoHS compliant

Meets moisture Sensitivity Level 1 requirements
