Honeywell Bi-Metallic Thermostat, Opens at +120°C, Closes at +105°C, +150°C Max, NC, Automatic Reset | 2455R–00820715

Snap action bi-metallic disc operates an SPST contact which is electrically isolated from the mounting bracket.
All types reset when the temperature falls to nominally 15° below operating temperature.
• Phenolic body with stainless steel end cap.
• 1/4in tab termination.
• Contacts are rated to 250 Vac 10A with a maximum contact resistance of 50 mΩ.
• Dielectric strength of 2000 Vac.
• N/C types open on temperature rise.
• N/O types close on temperature rise.

UL recognised component, CSA Certified

If you have precise temperature control requirements, this Honeywell bi-metallic thermostat is ideal. The SPST (single pole, single throw) snap-action switch is normally closed and opens when the temperature rises to +120°C. It automatically resets (closes) at 15°C below a nominated operating temperature of +105°C. This device can be used for many different commercial applications, including high-current heating, ventilation and air conditioning installations (HVAC), copy machines and heat or smoke detection. The maximum operating current for the sturdy unit is 10A.

• Quick-connect terminal type for ease of installation
• Small product size allows enhanced response to temperature changes
• Quality phenolic body with stainless steel end cap for longevity
• Wide operating temperature range of 0°C to +150°C for versatile use

• Automotive industry
• Industrial heaters
• Heavy-duty ovens

This device is fitted with quick-connect terminals for simple and efficient installation. As part of Honeywell’s 2455R series of thermostats, it’s compatible with a wide variety of mounting brackets and terminals to suit the needs of your individual application.
