Specifications
| Attribute | Value |
|---|---|
| Brand | Honeywell |
| Actuator Type | Lever |
| Terminal Type | Screw |
| Contact Current Rating | 15 A |
| Contact Configuration | SP-CO |
| Operating Force | 1.39 N |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +85°C |
| Contact Material | Silver |
| Case Material | Phenolic |
| Mechanical Life | 20000000Operations |
| Release Force | 0.14N |
| Operating Temperature Range | -55 → +85°C |
| Standards Met | CE Certified, CSA, UL |
Product Details
BZ Series Switches
Elongated mounting hole for easier, more accurate mounting
Current rating ranges from 15 A to 25 A
Typical applications include: irrigation systems, timing devices, test instruments and medical/dental equipment
Honeywell Microswitch, Phenolic Housing Material, 1.39N Operating Force – BZ Series – BZ-2RL-A2
Features & Benefits
• Screw terminals for a stable electrical connection
• Wide operating temperature range between -55°C and +85°C for use in demanding settings
Applications
• HVAC systems
• Construction sites
• Agricultural equipment
