Honeywell Piezoresistive Pressure Sensor, 103.421 kPa Operating Max | ABP2LANT015PA2A3XX
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: ABP2LANT015PA2A3XX
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Honeywell |
| Product Type | Piezoresistive Pressure Sensor |
| Maximum Operating Pressure | 103.421 kPa |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 110°C |
| Series | ABP |
| Standards/Approvals | No |
| Minimum Operating Pressure | 103.421kPa |
Product Details
The Honeywell ABP2 series are piezoresistive silicon pressure sensor offering a digital output for reading pressure over the specified full scale pressure span and temperature range. They are calibrated and temperature compensated for sensor offset, sensitivity, temperature effects and accuracy errors (which include non-linearity, repeatability and hysteresis) using an on-board Application Specific Integrated Circuit (ASIC). it has calibrated output values for pressure and temperature are updated at approximately 200 Hz.
24-bit digital I2C or SPI-compatible output
IoT (Internet of Things) ready Interface
Ultra-low power consumption
Calibrated over wide temperature range of -40°C to 110°C
Long-term stability as low as ±0.2 %FSS
