Honeywell Plunger Limit Switch, 2NO/2NC, DPDT, Die Cast Aluminium Housing, 250V ac Max, 10A Max | DTF2-2RN-LH
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 12 pcs
Mfr. Part No: DTF2-2RN-LH
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Honeywell |
| Actuator Type | Plunger |
| Pole and Throw Configuration | DPDT |
| Normal State Configuration | 2NO/2NC |
| Maximum Current | 10A |
| Housing Material | Die Cast Aluminium |
| Maximum AC Voltage | 250V |
| Maximum DC Voltage | 250V |
| Connection Type | 1/2 in NPT |
| Action Type | Snap Action |
| Length | 101.6mm |
| Depth | 54.86mm |
| Minimum Operating Temperature | -32°C |
| Maximum Operating Temperature | +71°C |
| Width | 33.02mm |
| Mounting Orientation | Vertical |
Product Details
DTF2 Medium Duty Limit Switches
The DTF2 limit switch series from Honeywell is designed for use within a medium duty environment. The elastomer boot on sealed actuator verions protects the actuating mechanism and the internal basic switch from contaminants. There is a seal gasket between the cover plate and the enclosures on all versions. The cover plate is removed for ease of wiring and switch replacement without demounting the switch. The actuator position is designated “right” or “left,” when looking at the nameplate.
Cast aluminium housing
Approvals
UL, CSA.
