Honeywell Through Hole Digital Hall-Effect Device 3.8 V 30 V, Digital, TO-92, 3-Pin | SS441A
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: SS441A
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Honeywell |
| Sensor Type | Minute |
| Product Type | Digital Hall-Effect Device |
| Technology | Hall Effect Technology |
| Mount Type | Through Hole |
| Magnetic Type | Unipolar |
| Interface Type | Digital |
| Minimum Supply Voltage | 3.8V |
| Maximum Supply Voltage | 30V |
| Package Type | TO-92 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 3 |
| Maximum Operating Temperature | 150°C |
| Series | SS |
| Width | 1.57 mm |
| Standards/Approvals | No |
| Height | 3mm |
| Length | 4.06mm |
| Automotive Standard | No |
| Supply Current | 20mA |
Product Details
The Honeywell SS400 Series and SS500 Series are small and versatile digital Hall-effect devices that are operated by the magnetic field from a permanent magnet or an electromagnet, and are designed to respond to alternating North and South poles, or to a South pole only. They are available in bipolar, latching or unipolar magnetics. On-board regulation provides stable operation over a 3.8 Vdc to 30 Vdc supply voltage range.
Quad Hall IC design minimizes mechanical stress effects
Temperature-compensated magnetics help provide stable operation over a wide temperature range of -40°C to 150°C [-40°F to 302°F]
Broad, inclusive supply voltage capability from 3.8 Vdc to 30 Vdc for application flexibility
Digital, open collector sinking output for easy interfacing with a variety of common electronic circuits
High sensitivity versions available for potential applications requiring high accuracy or wide gaps
Bipolar, latching or unipolar magnetics
