Honeywell Toggle Switch, Panel Mount, On-On, DPDT, Screw Terminal | 2TL1-3
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: 2TL1-3
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Honeywell |
| Contact Configuration | DPDT |
| Switch Operation | On-On |
| Contact Current Rating | 15 A @ 115 V ac, 20 A @ 28 V dc, 6 A @ 230 V ac |
| Mounting Type | Panel Mount |
| Terminal Type | Screw |
| Panel Cut Out Width | 11.9mm |
| Panel Cut Out Diameter | 10.9mm |
| Actuator Length | 17mm |
| Actuator Material | Metal, Plastic |
| Contact Material | Gold Plated Silver Alloy |
| Minimum Operating Temperature | -65°C |
| Maximum Operating Temperature | +71°C |
| Standards Met | CE Certified, CSA, UL |
| Operating Temperature Range | -65 → +71°C |
Product Details
Honeywell Toggle Switch, 17mm Actuator Length, 230V AC – TL Series – 2TL1-3
Easily turn your electrical devices on and off with this toggle switch from Honeywell. To prevent accidental activation, it features a pull-to-unlock lever, which means you must pull the toggle upwards for the device to switch on. The built-in actuator measures just 17mm in length, making this product suitable for installation in compact circuits. Its internal contacts are made from gold-plated silver alloy to ensure high conductivity and resistance to corrosion for a reliable connection. You can quickly and securely install this item on your control panel thanks to its screw terminal.
Features & Benefits
• Wide operating temperature range of -65°C to +71°C for use in harsh environments
• DPDT (double pole double throw) configuration to control multiple circuits for versatility
• DPDT (double pole double throw) configuration to control multiple circuits for versatility
Applications
• Commercial aviation
• Construction equipment
• Medical instrumentation
• Construction equipment
• Medical instrumentation
What’s a toggle switch?
You can use a toggle switch to turn a device on and off by way of a lever. Depending on the direction of the lever, it will either cut the flow of current or create a path for the current. An example of this would be a basic light switch.
