Honeywell Toggle Switch, Panel Mount, (On)-On-(On), DPDT, Screw Terminal | 2NT1-70
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: 2NT1-70
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Honeywell |
| Contact Configuration | DPDT |
| Switch Operation | (On)-On-(On) |
| Contact Current Rating | 11 A @ 115 V AC, 18 A @ 28 V DC, 6 A @ 230 V AC |
| Mounting Type | Panel Mount |
| Terminal Type | Screw |
| IP Rating | IP67, IP68 |
| Panel Cut Out Diameter | 12.4mm |
| Actuator Length | 17mm |
| Actuator Material | Metal, Plastic |
| Panel Cut Out Size | 12.4 (Dia)mm |
| Contact Material | Gold Plated Silver Alloy |
| Operating Temperature Range | -40 → +71°C |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +71°C |
Product Details
Honeywell NT Series Toggle Switches
These sealed commercial grade toggle switches are designed for demanding outdoor enviroments, where the panels are subjected to vibration, temperature extremes, dust and water.
Tactile feedback of toggle for gloved operation
NEMA 3, 3R, 4, 13 and IP67/68 sealing
NEMA 3, 3R, 4, 13 and IP67/68 sealing
Approvals
UL, CSA, CE
Honeywell Toggle Switch, 3 Positions, Panel Mounting – NT Series – 2NT1-70
Use this toggle switch from Honeywell to control your machine processes. It supports both maintained and momentary toggle operations for fast switching between your appliance functions. The device’s spring-loaded lever actuator gives tactile feedback, so you can be confident it’s activated, even when wearing gloves. Thanks to its IP67 rating, it’s dust-tight and can withstand submersion in 1m of water for up to 30 minutes.
Features & Benefits
• Wide operating temperature range of -65°C to +71°C for use in demanding environments
• Designed for panel mounting for ease of installation
• Short actuator length of 17mm ensures it doesn’t protrude too far from the panel to prevent accidental activation
• Designed for panel mounting for ease of installation
• Short actuator length of 17mm ensures it doesn’t protrude too far from the panel to prevent accidental activation
Applications
• Cranes and lifts
• Lighting systems
• Agricultural industry
• Lighting systems
• Agricultural industry
What are maintained and momentary toggle actions?
Maintained toggle actions mean the switch stays in position until it’s actuated again. Momentary toggle actions mean the switch only stays in position while it’s actively held there.
