HPMA115C0-003 Honeywell Air Quality Sensor 650 nm UART 8-Pin | HPMA115C0-003
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 15 pcs
Mfr. Part No: HPMA115C0-003
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Honeywell |
| Product Type | Air Quality Sensor |
| Peak Wavelength | 650nm |
| Mount Type | Screw |
| Maximum Frequency | 100kHz |
| Pin Count | 8 |
| Interface Type | UART |
| Minimum Supply Voltage | 4.8V |
| Maximum Supply Voltage | 5.2V |
| Minimum Operating Temperature | -20°C |
| Width | 36 mm |
| Length | 43mm |
| Series | HPM |
| Standards/Approvals | RoHS, IEC61000, REACH |
| Height | 23.7mm |
| Maximum Operating Temperature | 70°C |
| Supply Current | 80mA |
| Automotive Standard | No |
| Technology | Laser Scattering |
Product Details
The Honeywell HPM Series PM 2.5 Particulate Matter Sensor is a compact size laser-based sensor which detects and counts particles using light scattering. The detection concentration range is 0 μg/m3 to 1,000 μg/m3.
operation over a wide temperature range
