i-Autoc KSI Series Solid State Relay, 10 A Load, Panel Mount, 530 V ac Load, 32 V dc Control | KSI480D10-L
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 12 pcs
Mfr. Part No: KSI480D10-L
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | i-Autoc |
| Maximum Load Current | 10 A |
| Mounting Type | Panel Mount |
| Maximum Load Voltage | 530 V ac |
| Minimum Load Voltage | 48 V ac |
| Minimum Control Voltage | 4 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Zero Cross |
| Control Voltage Range | 4 → 32 V dc |
| Terminal Type | Screw |
| Output Device | SCR, TRIAC |
| Relay Type | Single Phase |
| Maximum Turn On Time | 10ms |
| Load Voltage Range | 48 → 530V ac |
| Series | KSI |
| Dimensions | 58.4 x 45.7 x 20.5mm |
| Height | 20.5mm |
| Depth | 45.7mm |
| Operating Temperature Range | -30 → +80°C |
| Length | 58.4mm |
| Maximum Operating Temperature | +80°C |
| Off State Leakage Current | 5 mA |
| Special Features | Build-In MOV/TVS Option, DC Control, Dielectric Strength, LED Indicator, TRIAC or SCR Output |
| Minimum Operating Temperature | -30°C |
| Standards Met | CCCs, CE, CULus, TUV |
Product Details
KSI series single phase solid state relay use the Triac or SCR output. It is widely used in various industry applications, and it can be used for the resistive, inductive or capacitive loads. The control voltage is 4-32VDC or 90-280VAC, load voltage is 240VAC, 380VAC, 480VAC or 600VAC. Wide load current range from 10 to 125A.
Zero crossing or Random-on
Load current:10A-125A @48-660VAC
TRIAC or SCR output
AC or DC control
Dielectric strength ≥4000VACrms
LED indicator
Build-in MOV or TVS option
Load current:10A-125A @48-660VAC
TRIAC or SCR output
AC or DC control
Dielectric strength ≥4000VACrms
LED indicator
Build-in MOV or TVS option
