Idec HE2B Series Safety Enabling Switch, 3 Position, SPST, IP40 | HE2B-M222
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: HE2B-M222
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Idec |
| Series | HE2B |
| Product Type | Safety Enabling Switch |
| Contact Configuration | SPST |
| Number of Positions | 3 |
| IP Rating | IP40 |
| Terminal Type | Solder |
| Switch Contact Current | 3 A |
| Minimum Operating Temperature | -25°C |
| Housing Material | Silicon Rubber |
| Maximum Operating Temperature | 60°C |
| Contact Voltage | 250V |
| Hazardous Area Certification | No |
| Standards/Approvals | ANSI/RIA R15.06, UL508 (UL), ANSI B11.19, ISO12100-1-2/EN12100-1-2, IEC/EN60947-5-8 (TÜV Approval), IEC/EN60947-5-1, GB14048.5 (CCC Approval), CSA C22.2 No. 14 (c-UL), ISO10218/EN775, IEC60204-1/EN60204ISO11161/prEN11161 |
| Depth | 27.7mm |
| Mechanical Life | 100000Operations |
| Length | 16mm |
| Width | 87 mm |
Product Details
IDEC HE2B Series Redundant (Double) Basic Enabling Switch.
Ideally suited for use as an enabling switch on teach pendants, the function accomodates a panic situation wherein the operator can release or squeeze for the switch off position. The contact will not close when released from “Off” position 3 to “Off” position 1. Rubber covers are available in a choice of 3 colours, the cover provides a watertight seal. See typically Stock no 8077099
Multiple contacts for enhanced reliability
Monitoring contacts in addition to main load contacts
IP65 rated with fitted rubber cover
3 position operation Off-On-Off
Enabling Switch
Standards
IEC60947-5-1, EN60947-5-1, JIS C8201-5-1, UL508, CSA C22.2 No 14
