Idec HE5B Series Safety Enabling Switch, 3 Position, IP65 | HE9Z-GSH51
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: HE9Z-GSH51
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Idec |
| Product Type | Safety Enabling Switch |
| Series | HE5B |
| Number of Positions | 3 |
| IP Rating | IP65 |
| Terminal Type | Solder |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | 60°C |
| Hazardous Area Certification | No |
| Standards/Approvals | UL50, cURus, UKCA, IEC/EN 60529, CE |
| Depth | 38mm |
| Mechanical Life | 100000Operations |
| Width | 39 mm |
| Length | 222mm |
Product Details
IDEC HE5B Series Pushbutton Enabling Switch
Ideally suited for use as an enabling switch for manual robotic control. To assist the operator the “On” position requires only light pressure to maintain the function, a higher force is then required to switch from the “On” position to position 3. The contact will not close when released from “Off” position 3 to “Off” position 1. For a suitable IDEC “Pendant Grip” switch housing for HE5B, see RS Stock No. 807-7086. The HE5B series pushbutton enabling switch is the RS Stock No. 807-7112. Rubber boot switch button covers are available in Yellow, RS Stock No. 807-7121, in Black, RS Stock No. 807-7124, in Grey, RS Stock No. 807-7128.
IP65 rated with fitted rubber cover
Mounts in 16 mm round hole
3 position operation Off-On-Off
Enabling Switch
Standards
IEC60947-5-1, EN60947-5-1, JIS C8201-5-1, UL508, CSA C22.2 No 14
