Idec HE6B Series Safety Enabling Switch, 3 Position, DPDT, IP65 | HE6B-M211
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 15 pcs
Mfr. Part No: HE6B-M211
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Idec |
| Product Type | Safety Enabling Switch |
| Series | HE6B |
| Contact Configuration | DPDT |
| Number of Positions | 3 |
| IP Rating | IP65 |
| Terminal Type | Solder |
| Minimum Operating Temperature | -25°C |
| Switch Contact Current | 1 A |
| Maximum Operating Temperature | 60°C |
| Standards/Approvals | GB14048.5 (CCC Approval), ANSI B 11.19, ISO10218-1/EN ISO10218-1, ISO11161/EN ISO11161, UL508 (UL recgonised) CSA C22.2 No.14, ISO12100/EN ISO12100, ISO13849-1/EN ISO13849-1, ANSI/RIA/ISO10218-1, ANSI/RIA/R15.06, GS-ET-22 (TÜV Approval), (c-UL), IEC/EN60947-5-8 (TÜV Approval), IEC60204-1/EN60204-1, IEC/EN60947-5-1 |
| Hazardous Area Certification | No |
| Depth | 22mm |
| Mechanical Life | 100000Operations |
| Width | 47.7 mm |
| Length | 32mm |
Product Details
IDEC HE6B Enabling Switch
Ideally suited for use as an enabling switch for manual robotic control, the function accomodates a panic situation wherein the operator can release or squeeze for the switch off position. The contact will not close when released from “Off” position 3 to “Off” position 1. Rubber covers are available in a choice of 3 colours, see typically Stock no 8077146
IP65 rated with fitted rubber cover
3 position operation Off-On-Off
Enabling Switch
Standards
IEC60947-5-1, EN60947-5-1, IEC60947-5-8, EN60947-5-8, JIS C8201-5-1, UL508, CSA C22.2 No 14
