Idec Red Push Button LED Light for Use with A8 Series | LAD-SRN

Name: Idec Red Push Button LED Light for Use with A8 Series | LAD-SRN
SKU: 557-253
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 6 pcs

Mfr. Part No: LAD-SRN

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 557-253 Categories: Idec, Push Button Lamps & LEDs

Description

Specifications

Attribute	Value
Brand	Idec
Product Type	Push Button LED Light
For Use With	A8 Series
LED Colour	Red
Standards/Approvals	CSA, UL

Product Details

8mm Sub-miniature Illuminated Push-button Switches

8mm contact indicators for panel mounting

LED illumination, Suitable LEDs are supplied separately

Indicators are available in both square and round styles

Solder Tab terminals

LEDs

A range of LEDs specifically for use with this sub-miniature indicator series

Current should be limited to 20mA by use of a suitable external resistor as detailed at the beginning of the Optoelectronics/Indicators section. VF @ IF 20mA=1.7V (red), 2.1V (green) and 2.2V (yellow)

Note: When not illuminated, the green LED appears to be yellow.

Lenses

Two-part lenses comprising a diffuser and a coloured transparent front cover. Diffuser may be marked to indicate switch function, etc

Note

Square and round bezel indicators do not include a lens, switch or LED. Suitable lenses need to be ordered separately.

Document Download

Datasheet – A Series Miniature Control Units
LAD-SRN Datasheet
