Specifications
| Attribute | Value |
|---|---|
| Brand | IDEM |
| Normal State Configuration | 2NO/2NC |
| Cable Length | 100m |
| Mounting Orientation | Straight |
| IP Rating | IP67, IP69K |
| Number of Poles | 4P |
| Series | GLS-SS |
| Range | Guardian Line |
| Length | 239mm |
| Width | 65mm |
| Depth | 55mm |
| Housing Material | 316 Stainless Steel |
| Maximum DC Voltage | 250V |
| Conduit Entry | M20 |
| Maximum Current | 2.5A |
| Dimensions | 239 x 65 x 55mm |
| Maximum AC Voltage | 250V |
| Maximum Operating Temperature | +80°C |
| Minimum Operating Temperature | -25°C |
Product Details
IDEM Guardian Line GLS-SS Stainless Steel Safety Rope Pull Switches
They are designed to be mounted on machines and sections of conveyors which cannot be protected by guards and unlike emergency stop pushbuttons can be activated from any point along the length of rope pull to provide robust emergency stop protection.
In combination with a dual channel safety monitoring relay these safety rope switches can be used as emergency stop devices and monitored for up to Category 4 to EN 954-1 or PLe ISO 13849-1. The Guardian Line conforms to ISO 13850 and IEC 60947-5-5 and has a positive mechanical linkage between the switch contacts and the wire rope, as well as wire breakage monitoring. Once the rope is pulled, anywhere along its length, the safety contacts are positively opened and the auxiliary contacts are closed. The switches are mechanically latched and can only be returned to the operational condition by pressing the blue reset button, as required by ISO 13950.
Upto 80m (260 feet) can be covered using only a single switch and safety spring
Upto 100m (328 feet) can be covered using two switches
Positive break contacts to IEC60947-5-1
Stainless steel 316 housing
IP69 protection
Rugged integral sealing bellows mean they can be high pressure hosed
All internal screws are stainless steel
Easy to wire with 3 x M20 conduit entries
4 pole 2NO / 2 NC
