IDEM KP Safety Interlock Switch, 2NC/1NO, Keyed, Polyester | 200001-SS

The Kobra KP series from IDEM are tongue operated safety interlock switches that fit to the leading edge of sliding, hinged or lift off machine guards. These safety switches have positively operated switching contacts and a strong tamper resistant key mechanism designed to provide robust position interlock detection for moving guards.

Depending upon the risk assessment for the application, the Kobra KP can be used independently to provide positively operated contacts to EN60947-5-1 or can be used in combination with any dual channel safety monitoring relays to provide up to Category 4 PLe ISO13849-1 or SIL3 EN62061. A choice of contact blocks and various actuators are available to aid installation and maintain durability.

Positive break contacts to IEC 60947-5-1

High functional safety to ISO 13849-1

Contact blocks can be replaced

4 actuator entry positions

Rotatable heads

Polyester housing

Stock nos. 826-3928 and 826-3937 have stainless steel heads

3 or 4 pole contact blocks 2NC / 1NO, 3NC / 1NO or 4NC

3 conduit entry points M20

IP67 protection

Industry standard – 40mm fixing centres

Housing: 52 x 98 x 40mm

Only stock no. 826-3925 is supplied with a flat actuator. Standard, flat, plastic flexible, heavy duty flexible and hygienic actuators are available separately. The flexible actuators are perfect for tight radius guards. The hygienic actuator is made from stainless steel with a mirror polished finish.

CE, cULus, TUV.

EN1088, IEC 60947-5-1, EN60204-1, ISO 13849-1, EN62061, EN954-1, UL508.
