ifm electronic Background Suppression Distance Sensor, Barrel Sensor, 30 mm → 2 m Detection Range IO-LINK | OID200
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: OID200
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ifm electronic |
| Sensor Style | Barrel |
| Detection Type | Background Suppression |
| Detection Range | 30 mm → 2 m |
| Output Type | NPN/PNP |
| Electrical Connection | M12 Connector |
| Communication Protocol | IO-LINK |
| Maximum DC Voltage | 30V |
| Terminal Type | Wire Lead |
| Light Source | LED |
| IP Rating | IP65, IP67 |
| Maximum Current | 75 mA |
| Interface | IO-Link |
| Maximum Operating Temperature | +60°C |
| Housing Material | Stainless Steel |
| Minimum Operating Temperature | -25°C |
Product Details
IFM Photoelectric Distance Sensors
Photoelectric distance sensors are used where safe and non-contact detection of the exact position of objects is required. The IMF photoelectric distance sensor uses time-of-flight measurement which allows for a very long range.
Features and Benefits
• The IMF sensor measures distances in the range of 0.03m and 2m, with a background suppression of up to 20m.
• Reliable recognition of glossy surfaces with background suppression and colour independent detection.
• IO-link enables user friendly communication, which is also possible via connection using a USB adapter cable.
• Manually adjustable parameter setting using a turnable and lockable setting ring.
• The IMF sensor has an M30 barrel and an M12 connector.
• Visible laser light.
• Distance measuring.
• Reliable recognition of glossy surfaces with background suppression and colour independent detection.
• IO-link enables user friendly communication, which is also possible via connection using a USB adapter cable.
• Manually adjustable parameter setting using a turnable and lockable setting ring.
• The IMF sensor has an M30 barrel and an M12 connector.
• Visible laser light.
• Distance measuring.
