ifm electronic, DIN Rail Flow Controller, PNP Output 24 V dc | SR0127
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: SR0127
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ifm electronic |
| Product Type | Flow Controller |
| Terminal Type | Multi-Pin |
| Control Output | PNP |
| Display Screen | 11 x LED |
| Mount Type | DIN Rail |
| Minimum Operating Temperature | 0°C |
| Maximum Supply Voltage | 24V dc |
| Maximum Operating Temperature | 60°C |
| Standards/Approvals | RoHS Certificate of Compliance |
| Hazardous Area Certification | No |
| Current Rating | 400 mA |
Product Details
The ifm electronic Control Monitor for Flow Sensors is designed with a PNP electrical configuration and supports a permanent current rating of 400 mA for its switching output. It is programmed to activate the output when flow is detected and deactivate it in the event of a wire break. The device features pulsed short circuit protection and overload protection to ensure dependable performance. The switch point can be adjusted using an internal potentiometer. It operates within an ambient temperature range of 0 to 60°C and has an IP 50 rating for protection, with IP 20 protection for terminals.
For the connection of flow sensors
Integrated flow monitoring and wire monitoring
Intuitive setting of the switch point via potentiometer
Clearly visible multi-colour LED bargraph display
Signal output via semiconductor contacts
