ifm electronic Push Button, Panel Mount, 22mm Cutout, SPST | KT5106
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: KT5106
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ifm electronic |
| Panel Cut Out Diameter | 22mm |
| Mounting Type | Panel Mount |
| Push Button Colour | Green |
| Contact Configuration | SPST |
| Push Button Style | Round |
| Push Button Material | Polyamide |
| Manufacturer Part No. | KT5106 |
| Minimum Operating Temperature | -40°C |
| Maximum DC Voltage | 24V |
| Body Material | Polyamide |
| Terminal Type | Cable |
| Maximum Operating Temperature | +85°C |
Product Details
IFM KT Panel Mount Capacitive Touch Push Buttons
This range of panel mount capacitive push buttons from IFM offers a contactless solution to applications where a traditional mechanical push button may have been used. The contactless Push buttons are designed to meet an IP69K ingress protection rating and a wide temperature range of -40 °C to 85 °C making them highly versatile and suitable for use in industrial environments. Due to the capacitive sensing technology no physical contact or mechanical pressure is needed to actuate the button which reduces the wear and ultimately decreases maintenance cost for the end user.
Easy installation with M22 thread
IP69K ingress protection rating
Operating temperature of -40 °C to 85 °C
Wear free button actuation
M12 connector versions available
IP69K ingress protection rating
Operating temperature of -40 °C to 85 °C
Wear free button actuation
M12 connector versions available
Zero Force & Opto Touch Switches
Actuated by sensors using patented Field Effect Technology which converts the touch of the operators hand into an electrical output. The two sensors have to be touched within 0.2 seconds of each other and can differentiate between a person’s hand and most solid objects/substances, as well as resistance to accidental actuation via clothing, fluid, splashes etc.,There are built in diagnostic safeguards for power-up protection, foreign object intervention and film/deposit interference which all result in LED indication.
