ifm electronic Radar Distance Sensor Level Radar R1D101 | R1D101
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: R1D101
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ifm electronic |
| Product Type | Level Radar |
| Device Type | Radar Distance Sensor |
| Minimum Frequency | 60GHz |
| Maximum Frequency | 64GHz |
| IP Rating | IP67, IP65, IP69K, IP66 |
| Maximum Operating Temperature | 85°C |
| Standards/Approvals | cRUus, -6-2, -4-3, E1R, UL E205959, EN 55032 Class A, -4-4, CE, DIN EN 61000-4-2, -4-6, UKCA |
| Series | R1D101 |
| Length | 80mm |
| Depth | 45mm |
| Width | 80 mm |
Product Details
The ifm electronic radar distance sensor is designed to measure distances with high precision, making it an ideal solution for various applications requiring accurate positioning. With an operating voltage range of 9 to 32 DC and a maximum power consumption of 9 W, this sensor ensures reliable performance in challenging environments. Its compact rectangular housing measures 80 x 80 x 45 mm, providing easy integration into existing systems. The device supports a detection range of 0.1 to 50 m, and operates efficiently across a wide frequency spectrum of 60 to 64 GHz, delivering consistent measurements even in dynamic conditions. With various protection ratings including IP 65 to IP 69K, it excels in durability, ensuring longevity in demanding settings.
Communication via CAN interface, allowing seamless integration with other systems
Compact dimensions enable straightforward installation in confined spaces
Wide operating temperature range from -40 to 85 °C ensures functionality in extreme conditions
Robust protection class III with reverse polarity protection enhances operational safety
