ifm electronic SL5101 Series Flow Controller, 1000 cm³/s, Relay Output, 23 mm Pipe 24 V dc | SL5101
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: SL5101
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ifm electronic |
| Maximum Flow Rate | 1000cm³/s |
| Product Type | Flow Controller |
| Terminal Type | Cable |
| Control Output | Relay |
| Display Screen | LED |
| Maximum Pipe Diameter | 23mm |
| Minimum Operating Temperature | -10°C |
| Maximum Supply Voltage | 24V dc |
| Maximum Operating Temperature | 50°C |
| Standards/Approvals | UL, CE |
| Hazardous Area Certification | No |
| Series | SL5101 |
| Current Rating | 3 A |
Product Details
ifm electronic Airflow Sensor/Switch
The ifm electronic airflow sensor/switch can sense a maximum flow rate of 1000cm³/s; working on the calorimetric principle. It has a supply voltage rating of 24VDC. The immersion depth into the duct can be flexibly varied via the supplied mounting clamp. This sensor has a working range of 1 to 10m/sec (air velocity) and can be set to give an output signal should the airflow drop below the preset level.
Features and Benefits
• Reliable airflow monitoring
• User-friendly setting of the requested immersion depth of the sensor
• Intuitive setting of the switch point via a potentiometer
• Signal output via potential-free relay contacts
• LED status indication of power/airflow
• Insertion depth is 32mm (minimum), 120mm (maximum)
• Switching point continuously adjustable
• Dimensions: Length is 140mm; Diameter is 23mm
• Supplied with mounting clamp and installation instructions
• Pipe diameter range is 23mm
Applications
• Ventilation systems in building automation
• Airflow monitoring in ventilation systems and/or suction operations
• Monitoring in HVAC applications
Certifications
• CE certified
• UL listed
• DIN EN 61000-6-2
• DIN EN 61000-6-3
• CRN certified
• IP65 rated
