ifm electronic SN0150 Series, DIN Rail Flow Controller, Relay Output 240 V ac | SN0150
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: SN0150
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ifm electronic |
| Product Type | Flow Controller |
| Terminal Type | Combicon Connector |
| Control Output | Relay |
| Mount Type | DIN Rail |
| Display Screen | LED |
| Minimum Operating Temperature | -20°C |
| Maximum Supply Voltage | 240V ac |
| Maximum Operating Temperature | 60°C |
| Hazardous Area Certification | No |
| Standards/Approvals | UL, CE |
| Series | SN0150 |
| Current Rating | 4 A |
Product Details
ifm electronic Control Monitor For Flow Sensor
The ifm electronic control monitor for flow sensor operates. It has 3 switching functions one is relay energised when the flow is present and during the power-ON delay time for flow monitoring, second is relay energised when the temperature is exceeded for temperature monitoring and third is relay de-energised in case of wire break or short circuit for wire break monitoring. The input supply voltage rating ranging between 90VAC and 240VAC. The sensors are connected via pre-mounted comb icon connectors with screw terminals. The slim (25mm) control cabinet housing can be easily mounted on a DIN rail.
Features and Benefits
For the connection of flow sensors
Adjustable switching outputs for monitoring flow and temperature
Clearly visible multi-coloured LED bar graph display
Signal output via potential-free relay contacts with 4A current rating at 230VAC
Switch points configurable using a potentiometer
DIN rail mounting
Power consumption is 4VA
Combicon connector for electrical connection
Applications
Flow, temperature and wire-break monitoring
Industrial use
Certifications
CE certified
UL listed
