ifm electronic TW2000 Infrared Temperature Sensor, 0 °C to 999.5 °C | TW2000
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: TW2000
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | ifm electronic |
| Product Type | Infrared Temperature Sensor |
| Maximum Ambient Temperature | 65°C |
| Accuracy | ±1 % rgd |
| Minimum Temperature Sensed | 0°C |
| Maximum Temperature Sensed | 999.5°C |
| Terminal Type | M12 Connector |
| Mount Type | Screw |
| Diameter | 30 mm |
| Maximum Supply Voltage | 32V |
| Analogue Output Type | Analogue |
| Housing Material Sensing Head | Polyester, Stainless Steel (Threaded sleeve) |
| Response Time 90% | 100ms |
| IP Rating Sensing Head | IP65 |
| Series | TW |
| Configurable | Yes |
| Standards/Approvals | CE |
Product Details
TW2000
Ifm Electronic TW series non-contact infrared temperature sensors for the precise temperature measurement of hot objects or objects which are difficult to access. The measured value is provided via an analogue output, with an additional switching output available.
The TW series feature a high-quality precision lens for precise measurement. The lens withstands rough environments, for example in steelworks, and reduces the influence of external light to a minimum. To enable precise temperature measurement, the degree of emission can be quickly and easily set using the push buttons and display. The current temperature of the object to be measured is displayed during operation.
Features and Benefits
• 4 mA to 20 mA and switching output, freely programmable
• Adjustable for different target materials
• Scratch resistant precision lenses
• Easy handling via buttons and display
• Test function: activated on the sensor or remotely
ifm Electronic TW Series Infrared Temperature Sensors
