Legrand 3 Faceplate, Flush | 0 787 57
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: 0 787 57
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Legrand |
| Product Type | Faceplate |
| Connector Type | DALI, Female USB, IEEE 1394, LC Optical, RJ11, RJ12, RJ45, SC Optical Adapter, ST optical, SUB D, USB, Wiegand Protocol |
| Number of Gangs | 3 |
| Mount Type | Flush |
| Colour | White |
| Finish | Aluminium, Red, Tamperproof, White |
| Screwed/Screwless | Screwed |
| Material | Polycarbonate |
| Range | Mosaic |
| Standards/Approvals | No |
Product Details
Mosaic™ Audio and Video Sockets
3 Female RCA Audio and Video (Ref. 787 54)
Audio and video sockets used for composite video and stereo audio connections for all peripherals, amplifiers, mixing desks, DVD players, cameras, video players, video conferencing equipment etc.
Recommended cable: 1 shielded audio pair + 1 x 3 mm mini coaxial.
Max. cable length: 50 m (above the recommended length for composite video amps and audio amps).
Female HD15 (Ref. 787 57)
Video sockets for connection using 1 mm² section screw terminals.
Sub-D high-density, 15-point female connector.
Allows connection of VGA, XGA or VESA, a PC monitor, plasma screen, video projector, graphics tablet etc.
Recommended cable: VGA type (5 coax 75 Ω Ø 2.7 mm + 5 conductors Ø 2.7 – gauge 28)
Max. cable length: 25 m (above the recommended length for VGA amps).
Female BNC 75 Ω (Ref. 784 58)
Video sockets used for composite video connections for all peripherals such as DVD players, cameras, video players etc.
Recommended cable: RG59 coaxial.
Max. cable length: 50 m (above the recommended length for a composite video amp).
