MENNEKES Straight Switchable IP44 Industrial Interlock Socket 3+E, Earthing Position 6h, 32A, 400 V | 5105A
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: 5105A
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | MENNEKES |
| Plug/Socket | Socket |
| Product Type | Industrial Interlock |
| Pole Format | 3+E |
| Current | 32A |
| Switchable | Yes |
| Colour | Red |
| IP Rating | IP44 |
| Voltage | 400 V |
| Orientation | Straight |
| Earthing Position | 6h |
| Body Material | Thermoplastic |
| Length | 264mm |
| Width | 118 mm |
| Depth | 146mm |
| Standards/Approvals | No |
Product Details
Vertical
Fully interlocked switched (phase) sockets give enhanced electrical safety.
Switch cannot be energised until the plug is inserted
Plug cannot be withdrawn with the switch in the ON position, which prolongs contact life
16A – 63A can be padlocked in the OFF position
Housings are moulded from thermoplastic materials, giving insulation, strength and durability properties
Continuous polyurethane gasket between lid and base
Neutral block must be removed first before fitting auxillary contact block
* Has metric threads on mounting box cable entries
Standards
BS4343 (IEC/EN 60309-2)
