Specifications
| Attribute | Value |
|---|---|
| Brand | Norgren |
| Product Type | Pneumatic Sensor |
| Accuracy | 5 %FS |
| Switch Output | 2 x PNP |
| Pressure Type | Relative Pressure |
| Mount Type | Optional |
| Electrical Connection Type | M 12 x 1 (Contact Gold Plated) |
| Connection Thread Size | G 1/4 |
| Series | 34D |
| Minimum Set Pressure | -1bar |
| Maximum Set Pressure | 600bar |
| Connection Thread Standard | DIN ISO 228 |
| Maximum Operating Temperature | 80°C |
| Depth | 49.4mm |
| Standards/Approvals | DIN EN 60068-2-27, EN 61000-6-3, EN 61000-6-2, DIN EN 60529, DIN EN 60068-2-6 |
| Width | 34 mm |
| Height | 90.7mm |
