Novotechnik IP-6501 Series Position Sensor | IP-6501-A502

The industrial-grade potentiometer offers excellent linearity, long life, very good repeatability, and mechanical continuous rotation. Designed for severe working conditions in industrial applications, it features a water-protected housing, sturdy construction, and corrosion resistance. The shaft passage is sealed, and the connector meets protection class IP 65 standards.

Excellent linearity of ±0.075%, can be requested as ±0.025%
Long life with 100 x 10 movements typ.
Very good repeatability of 0.007°
Mechanical continuous rotation for versatile applications
Protection class IP 65 for durability in harsh environments
Stainless steel shaft with sealed passage for added protection
Conductive plastic resistance element for reliable performance
Precious metal multi-finger wiper assembly for precise readings
5-pin electrical connector for easy installation and operation
