Omron 400 V 0.9 kW Servo Motor, 1000 rpm, 19.3 Nm Max Output Torque, 22 mm Shaft Diameter | R88M-K90010C-S2

Name: Omron 400 V 0.9 kW Servo Motor, 1000 rpm, 19.3 Nm Max Output Torque, 22 mm Shaft Diameter | R88M-K90010C-S2
SKU: 8843-512
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 3 pcs

Mfr. Part No: R88M-K90010C-S2

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 8843-512 Categories: Omron, Servo Motors

Description

Specifications

Attribute	Value
Brand	Omron
Product Type	Servo Motor
Maximum Output Torque	19.3Nm
Supply Voltage	400 V
Sub Type	AC Servo Motor
Output Speed	1000rpm
Power Rating	0.9kW
Stall Torque	19.3Nm
Mount Type	Flange
Shaft Diameter	22mm
Length	225.5mm
Shaft Length	64mm
Width	130 mm
Depth	181mm
Current Rating	3.8 A
Series	Accurax G5
Rotor Inertia	6.7kg.m²
Standards/Approvals	No

Product Details

The Omron G5 series AC servo motors are standard and high inertia servo motor models having high resolution serial encoder provided by 20 bits encoder. They have IP67 standard and are low speed ripple and torque ripple due to low torque cogging.

Ultra-light and compact size motor

Various shaft, brake and seal options

Peak torque 300% of rated torque during 3 seconds or more depending on model
