Omron 400 V 7.5 kW Servo Motor, 1500 rpm, 47.8 Nm Max Output Torque, 42 mm Shaft Diameter | R88M-K7K515C-BOS2
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 7 pcs
Mfr. Part No: R88M-K7K515C-BOS2
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Omron |
| Product Type | Servo Motor |
| Maximum Output Torque | 47.8Nm |
| Supply Voltage | 400 V |
| Sub Type | AC Servo Motor |
| Output Speed | 1500rpm |
| Power Rating | 7.5kW |
| Stall Torque | 119Nm |
| Mount Type | Flange |
| Shaft Diameter | 42mm |
| Length | 450mm |
| Shaft Length | 109.8mm |
| Width | 176 mm |
| Depth | 272mm |
| Current Rating | 22 A |
| Series | Accurax G5 |
| Standards/Approvals | No |
| Rotor Inertia | 107kg.m² |
Product Details
The Omron G5 series AC servo motor ultra-light and compact size motor has standard and high inertia. It has low speed ripple and low torque ripple due to low torque cogging. It has high resolution serial encoder provided by 20 bits encoder with IP67 protection. It has rated output of 7.5 kW and rated speed 1500 rpm.
Rated torque 47.8 Nm
Rated speed 1500 Rpm
