Omron A22E Series, Twist Release, Emergency Stop Push Button Head | A22EL-M

Name: Omron A22E Series, Twist Release, Emergency Stop Push Button Head | A22EL-M
SKU: 0517-647
Availability: InStock

1 ₫

Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT

Đã bán: 9 pcs

Mfr. Part No: A22EL-M

Đánh giá: ⭐⭐⭐⭐⭐

SKU: 0517-647 Categories: Emergency Stop Push Button Heads, Omron

Description

Specifications

Attribute	Value
Brand	Omron
Series	A22E
Product Type	Emergency Stop Push Button Head
Push Button Actuation	Twist Release
Push Button Material	Plastic
IP Rating	IP65
Illuminated	Yes
Hazardous Area Certification	No

Product Details

A22E Series Emergency Stop Switch

The A22E series emergency stop switch is supplied as a complete or sub-assembled unit and can be installed in a 22mm or 25mm diameter hole. The switch unit can easily be mounted without the use of tools.

Direct opening mechanism to open the circuit when the contact welds

Safety lock mechanism prevents operating errors

Easy mounting and removal of Switch Blocks using a lever

Mount three Switch Units in series to improve wiring efficiency (with non-lighted Switch Units, three Units can be mounted for multiple contacts)

Finger protection mechanism on Switch Unit provided as a standard feature

Install using either round, or forked crimp terminals

Non-lighted models IP65 (oil-resistant), lighted models IP65

A lock plate is provided as a standard feature to ensure that the control box and switch are not easily separated

Completely Assembled Models

Non-lighted, 818-2009, 861-4616, 757-9089, 549-479, 841-1809 & 861-4610 (with Emergency Off legend)

Lighted, without voltage reduction unit, 757-9092 & 757-9095

Switch with Integrated Control Box

Non-lighted, 746-7154 & 746-7163

Operation Units only

Non-lighted 746-7166 & 746-7157

Lighted 746-7150

Switch Units only

Without voltage reduction unit, 861-4629 & 861-4622

With voltage reduction unit, 861-4626

Accessories

LED lamp, Red, 24 Vac/dc, 861-4635

Emergency Stop legend plate, 60mm dia. 757-9109

Emergency Off legend plate, 60mm dia. 746-7160

Control Box, yellow, 1 hole, 746-7179

E-Stop Shroud with Emergency Off legend, yellow, 746-7172

E-Stop Shroud, yellow, 746-7176 (no spacers) & 746-7185 (2 spacers)

Approvals

UL, cUL, TUV, CCC.

Standards

UL508 C22.2 No.14, EN60947-5-1 & EN60947-5-5 (certified direct opening mechanism), GB14048.5, EN60947-5-1.
