Omron Diffuse Photoelectric Sensor, Barrel Sensor, 1 m Detection Range | E3FB-DN23
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 7 pcs
Mfr. Part No: E3FB-DN23
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Omron |
| Sensor Style | Barrel |
| Detection Type | Diffuse |
| Detection Range | 1 m |
| Output Type | NPN |
| Switching Mode | Light / Dark switching |
| Electrical Connection | M12 4 Pin Connector |
| Maximum DC Voltage | 30V |
| Light Source | LED |
| IP Rating | IP67, IP69K |
| Maximum Current | 25 mA |
| Response Time | 500 μs |
| Series | E3F |
| Housing Material | Nickel Plated Brass |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +55°C |
| Thread Size | M18 |
Product Details
Omron E3F Series Photoelectric Sensor, 1m Detection Range, IP67/IP69K – E3FB-DN23
This photoelectric sensor is intended for precise detection in various automation and industrial applications. Using a diffuse detection method, it reliably identifies objects up to 1m away. Its robust housing provides excellent environmental protection, and it operates effectively in a wide temperature range, suitable for various working conditions.
Features & Benefits
• IP67 and IP69K ratings ensure strong dust and water protection
• Functions in temperatures from -25°C to +55°C
• 500μs response time enhances operational efficiency
• Functions in temperatures from -25°C to +55°C
• 500μs response time enhances operational efficiency
Applications
• Sensing in assembly lines
• Integration into packaging machines for object detection
• Use in material handling systems for accurate feedback
• Deployment in quality control systems for effective monitoring
• Integration into packaging machines for object detection
• Use in material handling systems for accurate feedback
• Deployment in quality control systems for effective monitoring
What is the maximum distance this sensor can detect?
The sensor can detect objects up to 1m away, ensuring suitable performance for various applications.
How does the NPN output function with controllers?
An NPN output means the sensor provides a low signal when activated, making it compatible with most industrial control systems.
What types of wiring connections can be used with it?
The sensor features an M12 4 pin connector for straightforward integration into existing systems.
How is the sensor protected from the environment?
With IP67 and IP69K ratings, it resists dust and water ingress, making it suited for various harsh environments.
E3F2 Series Barrel
Output can be configured by wiring either ’light ON’ or ’dark ON’
Built in amplifier
Short circuit and reverse polarity protection
M18 DIN size cylindrical housing
Built in amplifier
Short circuit and reverse polarity protection
M18 DIN size cylindrical housing
