Omron E5DC DIN Rail, Panel Mount PID Temperature Controller, 48 x 48mm 1 Input, 2 Output SSR, Solid State Relay, Logic, | E5DC-QX2DSM-002

This PID temperature controller is designed for precise temperature regulation in automation and industrial applications. With a compact size of 22.5 mm, it easily fits into narrow control panels and can be mounted on DIN rails. The controller supports various input types and can manage multiple output configurations.

• High-speed sampling at 50 ms enhances temperature control responsiveness
• SSR and linear current outputs provide versatile control options
• Universal input type accommodates thermocouples and resistance thermometers
• Adjustable ON/OFF and PID control methods optimise performance
• Removable screw terminal block simplifies maintenance tasks
• Integration with PLCs via programless communications for easy setup

• Integrated within industrial temperature control systems
• Used for precise monitoring and regulation of heating equipment
• Suitable for requiring PT100 thermocouple inputs
• Ideal for projects needing a robust and efficient solid state relay controller

The controller supports universal inputs, including thermocouples such as K, J, T, and PT100 resistance thermometers, allowing for flexibility in sensor choice.

Connections to the PLC can be made via the built-in RS-485 communication port, enabling straightforward integration with existing automation systems.

Regular checks of the wiring and signal connections are advised to ensure no corrosion or damage occurs. The removable terminal block facilitates easy inspection and replacement.

Yes, the temperature controller can be switched from automatic to manual operation, providing the ability to set specific target values or adjust parameters directly.

The solid state relay output can handle a maximum load current of 3 A, suitable for controlling various heating devices as part of your temperature regulation system.
