Omron E5DC DIN Rail, Panel Mount PID Temperature Controller, 48 x 48mm, 2 Output SSR, Solid State Relay, Logic, 100 → | E5DC-QX2ASM-017
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: E5DC-QX2ASM-017
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Omron |
| Output Type | SSR, Solid State Relay, Logic |
| Supply Voltage | 100 → 240 V ac |
| Size | 48 x 48mm |
| Number of Outputs | 2 |
| Minimum Operating Temperature | -10°C |
| Maximum Operating Temperature | +50°C |
| Temperature Range | +100 → +1800 (Type B Thermocouple) °C, 0 → +1300 (Type PL II Thermocouple) °C, 0 → +1700 (R & S Thermocouples) °C, 0 → +2300 (Type W Thermocouple) °C, -100 → +850 (Type J Thermocouple) °C, -100 → +850 (Type L Thermocouple) °C, -199.9 → +500 (JPT100) °C, -200 → +1300 (Type K Thermocouple) °C, -200 → +1300 (Type N Thermocouple) °C, -200 → +400 (Type T Thermocouple) °C, -200 → +400 (Type U Thermocouple) °C, -200 → +600 (Type E Thermocouple) °C, -200 → +850 (PT100) °C |
| Control Type | ON/OFF, PID, 2-PID Controller |
| Communication Module Available | No |
| Display Type | 11-Segment Digital Display |
| IP Rating | IP00, IP20 |
| Range | Omron E5DC |
| Mounting Type | DIN Rail, Panel Mount |
| Input Type | Universal, Platinum Resistance Thermometer, PT100, Thermocouple, Analogue |
| Series | E5DC |
| Additional Functionality | ON/OFF |
| Panel Depth | 85mm |
| Termination Type | Screw terminal block |
Product Details
E5DC Digital Temperature Controllers (22.5 mm wide)
The E5DC temperature controller is setting a new global standard in terms of precision and user-friendly design. Best control performance, easy set-up and outstanding visibility of the white LCD display have been integrated into a space-saving housing with only 22.5mm wide.
Fast and precise regulation: 50ms sampling loop period time
Easy to set up, and operate intuitively via CX-Thermo without power supply
Setup Tool Port on the front panel
Useful alarm and diagnosis functions for secure operation
Width of 22.5 mm
Removable terminal block for easy mounting and replacement
DIN rail mounting
Easy to set up, and operate intuitively via CX-Thermo without power supply
Setup Tool Port on the front panel
Useful alarm and diagnosis functions for secure operation
Width of 22.5 mm
Removable terminal block for easy mounting and replacement
DIN rail mounting
Omron – E5GC, E5CC, E5EC, E5AC, E5DC, E5CN & E5CB Ranges
