Omron Inductive Threaded Barrel Proximity Sensor, M30, 15 mm Detection, PNP NC, 10 → 30 V dc | E2E-X15B230-M1
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 8 pcs
Mfr. Part No: E2E-X15B230-M1
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Omron |
| Thread Size | M30 |
| Sensor Technology | Inductive |
| Detection Range | 15 mm |
| Body Style | Threaded Barrel |
| Output Function | NC |
| Digital Switching Output Type | PNP |
| Connection Type | M12 |
| Supply Voltage | 10 → 30 V dc |
| IP Rating | IP67, IP69K |
| Length | 58mm |
| Mounting Type | Quasi-Flush |
| Housing Material | Nickel-Brass |
| Maximum DC Voltage | 30V |
| Minimum Operating Temperature | -25°C |
| Shielding | Shielded |
| Maximum Switching Frequency | 200Hz |
| Switching Frequency | 200 Hz |
| Series | E2E |
| Standards Met | IEC 60529 |
| Switching Current | 3 → 100 mA |
| Maximum Operating Temperature | +70°C |
Product Details
Omron E2E Series Proximity Sensor, 10 to 30V DC Supply Voltage, IP67/IP69K – E2E-X15B230-M1
This inductive proximity sensor is designed for non-contact detection in various industrial applications. With a compact M30 threaded form factor, it offers precise sensing with a 15mm detection range. Its robust construction enhances durability in various environments, making it suitable for automation and machinery control.
Features & Benefits
• High IP67 and IP69K ratings protect against dust and water ingress
• Quasi-flush mounting style provides versatile installation options
• Nickel-brass housing gives protection and corrosion resistance
• Quasi-flush mounting style provides versatile installation options
• Nickel-brass housing gives protection and corrosion resistance
Applications
• Detecting objects in automated assembly lines
• Position sensing in packaging machinery
• Monitoring movement in conveyor systems for accurate material handling
• Suitable for movement detection in robotic
• Position sensing in packaging machinery
• Monitoring movement in conveyor systems for accurate material handling
• Suitable for movement detection in robotic
What supply voltage is needed for operation?
The sensor operates within a supply voltage range of 10 to 30V DC, ensuring compatibility with various systems.
How does the protection rating benefit installation?
The IP67 and IP69K ratings protect the sensor from dust and high-pressure water, promoting longevity in challenging environments.
What is the maximum switching frequency of the sensor?
The maximum switching frequency is 200Hz, providing efficient performance for high-speed applications.
What materials can it detect?
This inductive proximity sensor is primarily designed to detect metal objects, enhancing its applicability in industrial settings.
