Omron, J7TKN Thermal Overload Relay 1 NO/1 NC, 10 A F.L.C, 17 to 24 A Contact Rating, 44.301 kW, 0V 3P | J7TKN-B-24
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 10 pcs
Mfr. Part No: J7TKN-B-24
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Omron |
| Product Type | Thermal Overload Relay |
| FLC Motor Rating | 10 A |
| Relay Contact Current | 17 to 24 A |
| Series | J7TKN |
| Mount Type | Direct |
| Pole and Throw Configuration | 3P |
| Power Rating | 44.301kW |
| Normal State Configuration | 1 NO/1 NC |
| Reset Method | Automatic & Manual |
| Adjustable Current Range | 17 to 24 A |
| Minimum Operating Temperature | -25°C |
| Width | 45 mm |
| Number of Auxiliary Contacts | 2 |
| Length | 70mm |
| Contact Voltage | 690V |
| Maximum Operating Temperature | 60°C |
| Depth | 70mm |
| Standards/Approvals | UL, VDE 0660, EN/IEC 60947-4-1, IEC 60947-4-1 |
| Control Voltage | 0V |
Product Details
Omron Thermal Overload Relay, 17 to 24A Contact Current Rating, 1NC + 1NO – J7TKN-B-24
This thermal overload relay is designed with a setting range of 40-55 A to provide precise protection for motors against overload conditions. It operates at a maximum insulation voltage of 600V, ensuring reliability in demanding environments. With its compact dimensions and robust build, this relay is tailored for use with various contactors in industrial settings.
Features & Benefits
• Direct mounting simplifies installation and maintenance
• Operating range supports easy adaptability to motors
• Normal state configuration provides dual control options
• Power rating of 44.301kW enhances operational capacity
• Contact current rating up to 24A ensures functionality
• Single phasing sensitivity protects against electrical imbalance
Applications
• Used for motor protection in automated machinery
• Suitable for installation in electrical control panels
• Utilised in HVAC systems for thermal monitoring
• Appropriate for various mechanical industry applications
What is the maximum fuse size for this relay?
The maximum fuse size according to coordination is 25 A.
Can this relay be used in high ambient temperatures?
Yes, it operates within a range from -25 to 55°C.
Can it detect single phasing issues in motors?
Yes, it includes single phasing sensitivity features.
Is it compliant with international electrical standards?
Yes, it meets IEC and VDE standards for safety.
Can it be mounted onto existing control systems easily?
Yes, the direct mounting option allows for straightforward integration.
