Omron PCB Mount Latching Power Relay, 5V dc Coil, 5A Switching Current, SPST | G6BK-1114P-US DC5
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 8 pcs
Mfr. Part No: G6BK-1114P-US DC5
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Omron |
| Coil Voltage | 5V dc |
| Contact Configuration | SPST |
| Mounting Type | PCB Mount |
| Switching Current | 5A |
| Latching | Yes |
| Terminal Type | Through Hole |
| Maximum Switching Voltage AC | 380V ac |
| Maximum Switching Voltage DC | 125V dc |
| Length | 20mm |
| Coil Resistance | 89.2 Ω |
| Coil Power | 280mW |
| Minimum Operating Temperature | -25°C |
| Life | 50000000 (Mechanical) cycles |
| Height | 10mm |
| Depth | 10mm |
| Isolation Coil To Contact | 3kV ac |
| Maximum Operating Temperature | +70°C |
| Contact Material | Silver Alloy |
| Maximum Switching Power DC | 150 W |
| Maximum Switching Power AC | 1.25 kVA |
| Dimensions | 20 x 10 x 10mm |
| Application | Power |
Product Details
G6BK Latching
Double winding latching
Fully sealed
Switching Voltage: 30Vdc; 250Vac
Mechanical Life: 50 x 106
Contact Resistance: 30mΩ
Contact Material: AgCdO
H11, W20, D10mm
Fully sealed
Switching Voltage: 30Vdc; 250Vac
Mechanical Life: 50 x 106
Contact Resistance: 30mΩ
Contact Material: AgCdO
H11, W20, D10mm
Approvals
UL recognised; CSA certified
Approvals
UL; CSA
