Omron PCB Mount Power Relay, 240V ac Coil, 25A Switching Current, 3PDT | G7J-3A1B-P AC200/240
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: G7J-3A1B-P AC200/240
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Omron |
| Coil Voltage | 240V ac |
| Contact Configuration | 3PDT |
| Mounting Type | PCB Mount |
| Switching Current | 25A |
| Latching | No |
| Series | G7J |
| Terminal Type | Through Hole |
| Maximum Switching Voltage AC | 250V ac |
| Maximum Switching Voltage DC | 125V dc |
| Length | 51.5mm |
| Coil Power | 2.6W |
| Height | 51mm |
| Minimum Operating Temperature | -25°C |
| Life | 1000000 (Mechanical) cycles |
| Maximum Operating Temperature | +60°C |
| Isolation Coil To Contact | 4kV ac |
| Depth | 33.5mm |
| Maximum Switching Power DC | 750 W |
| Maximum Switching Power AC | 5.5 kVA |
| Application | Power |
Product Details
PCB Mounting & Screw Terminal – Power Relays – G7J Series
High capacity, high dielectric strength, multi-pole relays ideal for 3-phase motor control applications and resistive loads
No contact chattering for momentary voltage drops up to 50% of rated voltage
Withstands more than 4kV between contacts that are of different polarity and between the coil and contacts
Flame-resistant material (UL94V-0)
Push-to-test button lets user check contact operation
PCB mounted, screw terminal or quick connect types available
No contact chattering for momentary voltage drops up to 50% of rated voltage
Withstands more than 4kV between contacts that are of different polarity and between the coil and contacts
Flame-resistant material (UL94V-0)
Push-to-test button lets user check contact operation
PCB mounted, screw terminal or quick connect types available
Approvals
UL; CSA
