Omron PCB Mount Power Relay, 5V dc Coil, 16A Switching Current, SPST | G2RL-1A4-E DC5
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 6 pcs
Mfr. Part No: G2RL-1A4-E DC5
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Omron |
| Coil Voltage | 5V dc |
| Contact Configuration | SPST |
| Mounting Type | PCB Mount |
| Switching Current | 16A |
| Number of Poles | 1 |
| Latching | No |
| Terminal Type | Through Hole |
| Length | 29mm |
| Coil Resistance | 62.5Ω |
| Contact Material | Silver |
| Minimum Operating Temperature | -40°C |
| Series | G2RL |
| Height | 15.7mm |
| Depth | 12.7mm |
| Maximum Operating Temperature | +85°C |
| Maximum Switching Power AC | 4 kVA |
| Application | Power |
Product Details
G2RL Series
Low profile 15.7mm height (max.)
10mm creepage/clearance
Meets EN60335-1 requirements
Tracking resistance: CTI>250
H15.7, W12.7, D29mm
10mm creepage/clearance
Meets EN60335-1 requirements
Tracking resistance: CTI>250
H15.7, W12.7, D29mm
Approvals
UL recognised; CSA certified; VDE
