Omron PCB Signal Relay, 3 V dc Coil, 2 A, DPDT | G5V-2 3DC
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 8 pcs
Mfr. Part No: G5V-2 3DC
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Omron |
| Product Type | Signal Relay |
| Coil Voltage | 3 V dc |
| Contact Configuration | DPDT |
| Mount Type | PCB |
| Switching Current | 2 A |
| Switching AC Voltage | 125 V |
| Switching DC Voltage | 125 V dc |
| Series | MT |
| Switching Power | 62.5VA |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | 70°C |
| Standards/Approvals | RoHS |
| Width | 10 mm |
| Height | 11mm |
| Length | 20.2mm |
| Terminal Type | Through Hole |
| Contact Material | Gold Plated |
| Coil Power | 500mW |
| Coil Resistance | 60Ω |
Product Details
G5V-2 Series
Fully sealed for immersion cleaning
Conforms to BT Type 47 requirements, BT specification 4597
Ideal for signal switching applications
Approvals
UL, CSA conforms to FCC part 68
