Omron Plug In Power Relay, 24V ac Coil, 10A Switching Current, SPDT | G2R-1-SN 24VAC (S)
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 14 pcs
Mfr. Part No: G2R-1-SN 24VAC (S)
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Omron |
| Coil Voltage | 24V ac |
| Contact Configuration | SPDT |
| Mounting Type | Plug In |
| Switching Current | 10A |
| Number of Poles | 1 |
| Series | G2R-1 |
| Latching | No |
| Terminal Type | Quick Connect |
| Maximum Switching Voltage AC | 440V ac |
| Maximum Switching Voltage DC | 125V dc |
| Maximum Switching Current DC | 10 A |
| Maximum Switching Current AC | 10 A |
| Length | 29mm |
| Coil Resistance | 260Ω |
| Coil Power | 900mW |
| Minimum Operating Temperature | -40°C |
| Standards Met | CE, CSA |
| Maximum Operating Temperature | +70°C |
| Isolation Coil To Contact | 5kV ac |
| Life | 1000000 (Electrical) cycles, 10000000 (Mechanical) cycles |
| Height | 29mm |
| Contact Material | Silver Alloy |
| Depth | 13mm |
| Maximum Switching Power DC | 300 W |
| Maximum Switching Power AC | 2.5 kVA |
| Dimensions | 29 x 13 x 29mm |
| Application | Power |
Product Details
G2RS Series Non-Latching Relay
Omron G2RS Series industrial plug-in relays are compact, electromechanical space saving relays. The relays are ideal for you to use in various general purpose applications.
Features & Benefits
Integral Coil status LED and mechanical operation indicator
Cadmium and lead free
Contact resistance: 100 mΩ
Coil to contact isolation: 5000 V ac
Operating temperature range: -40 → + 70°C
H35.5, W29, D13mm
DIN Rail and PCB sockets are available separately
Cadmium and lead free
Contact resistance: 100 mΩ
Coil to contact isolation: 5000 V ac
Operating temperature range: -40 → + 70°C
H35.5, W29, D13mm
DIN Rail and PCB sockets are available separately
Product Application Information
Medical Health Care Profession
Lifts and Elevators
Gas and electric boilers
Domestic Appliances
Lifts and Elevators
Gas and electric boilers
Domestic Appliances
Note
Can be used as a replacement for earlier version of G2R-SN series, check height clearance.
Approvals
UL, CSA, VDE
OMRON Power Relay, 29 (L) x 13 (W) x 35.5mm (H), 900mW Coil Power – G2R-1 Series – G2R-1-SN AC24(S)
Want fuss-free circuit management? Add this power relay from OMRON to your system. It has a 10A switching current capacity that kicks your motor or heating system into action in a flash. At just 13mm wide, the device slots neatly into tight spaces without sticking out like a sore thumb. For convenient installation, you can simply click it into place by hand thanks to its plug-in mounting design.
Features & Benefits
• Transparent casing and operating-status LED make monitoring easy
• Light 20g weight keeps strain minimal
• Performs reliably in temperatures between -40°C and +70°C, so you can trust it in harsh industrial settings
• Silver-alloy contacts resist corrosion for a long service life
• Light 20g weight keeps strain minimal
• Performs reliably in temperatures between -40°C and +70°C, so you can trust it in harsh industrial settings
• Silver-alloy contacts resist corrosion for a long service life
Applications
• Medical equipment
• Telecommunications industry
• Industrial automation
• Telecommunications industry
• Industrial automation
What’s the mechanical lifespan of this power relay?
This power relay handles at least 10 million mechanical cycles, so it’s a reliable choice that delivers long-term performance.
Is this device a good fit for demanding applications?
Yes. It copes with up to 1,800 operations per hour, making it an ideal option for use with heavy-duty equipment.
Approvals
VDE; TUV; UL; CSA; SEMKO; IMQ
