Otto P9 Series Push Button Switch, Momentary, Panel, 0.505 x 0.460 in Cutout, SPDT, Red LED, IP64, 28 V dc 115 V ac | P9-613121

Momentary action P9 series push button switches feature a contoured dome style push button in either a low button profile or a high button profile with a threaded case for hex nut mounting and a short behind panel depth of approximately 12mm. At a full rated load of 5 amps resistive or 3 amps inductive the P9 life is approximately one million mechanical operations with an electrical life of 25,000 operations. The P9 series has a low contact resistance for low level switching capability as well as being a precision designed switch for use in panels, control grips, computers, instruments, heavy equipment and other demanding applications where attractive rugged push button switches are required.

Black bezel and body with a choice of flush and raised dome button cap styles

Choice of button cap colours

Sealed to IP64

Withstands extreme shock & vibration

Positive tactile feedback

15/32-32 threaded body

Moistureproof and dust tight to IP64

For white body versions see stock number 737-3787 typically.
For panel sealing use gasket stock number 737-3863.

UL; CSA
