Panasonic 1 mF Surface Mount Polymer Capacitor, 16 V | 16SVPF1000M
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 4 pcs
Mfr. Part No: 16SVPF1000M
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Panasonic |
| Technology | Polymer |
| Product Type | Polymer Capacitor |
| Capacitance | 1mF |
| Voltage | 16 V |
| Mount Type | Surface Mount |
| Package/Case | 400 |
| Polarity | Polar |
| Lead Pitch | 4.6mm |
| Tolerance | ±20 % |
| Maximum Operating Temperature | 105°C |
| Dimensions | 10 (Dia) x 12.6 mm |
| Series | SVPF |
| Height | 12.6mm |
| Depth | 10.3mm |
| Length | 12.6mm |
| Electrolyte Type | Solid |
| Diameter | 10 mm |
| Lifetime | 5000 h |
| Ripple Current | 5.4A |
| Leakage Current | 3200μA |
| Automotive Standard | No |
| Dissipation Factor | 12% |
| Minimum Operating Temperature | -55°C |
Product Details
OSCON Solid Electrolytic SVPF series
Panasonic OS-CON SVPF electrolytic capacitors have a solid aluminium construction with a high conductive polymer. These aluminium capacitors cater for high voltage up to 50 V dc and feature large capacitance up to 1000μF.
Surface mount
5000 h guarantee at +105°C
Excellent noise reduction capability
Long life span
High voltage
High reliability
High ripple current
Halogen free
Applications
These surface mount capacitors are recommended for use in industrial infrastructure in industrial PCs, motor drivers, measuring instruments, power supplies, security cameras and inverters. SVPF OS-CON capacitors are also suitable for home appliances such as Air conditioners and home information appliances. Suitable uses for these electrolytic capacitors include infotainment and comfort accessories within automotive applications and ICT applications such as PCs, base stations, SSD and data centres.
