Panasonic 10 μF Surface Mount Polymer Capacitor, 50 V | EEHZA1H100R
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 16 pcs
Mfr. Part No: EEHZA1H100R
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Panasonic |
| Technology | Hybrid |
| Product Type | Polymer Capacitor |
| Capacitance | 10μF |
| Voltage | 50 V |
| Mount Type | Surface Mount |
| Polarity | Polar |
| Lead Pitch | 1.5mm |
| Tolerance | ±20 % |
| Maximum Operating Temperature | 105°C |
| Dimensions | 5 (Dia) x 5.8 mm |
| Length | 5.8mm |
| Height | 5.8mm |
| Series | ZA |
| Electrolyte Type | Hybrid |
| Ripple Current | 750mA |
| Automotive Standard | AEC-Q200 |
| Lifetime | 10000 h |
| Minimum Operating Temperature | -55°C |
| Leakage Current | 5μA |
| Diameter | 5 mm |
| Dissipation Factor | 10% |
Product Details
Panasonic Series ZA Polymer Capacitor, 10μF Capacitance, 50V DC Voltage – EEHZA1H100R
This polymer capacitor is a surface mount component, specialising in hybrid technology with a capacitance Value of 10 μF. Designed for applications requiring precision and reliability, it operates within a voltage range of up to 50V DC. Its Compact size (5mm diameter and 5.8mm height) facilitates integration into various electronic devices, enhancing overall performance and efficiency.
Features & Benefits
• Low equivalent series resistance of 120 mΩ enhances efficiency
• High-temperature operation up to +105 °C suits demanding applications
• Polarised design ensures correct usage in circuits
• Long operational life of 10,000 hours reduces maintenance needs
• Minimal leakage current of 5 μA contributes to energy efficiency
• Compatible with surface mount technology for ease of integration
Applications
• Used for automotive electronic systems ensuring compliance with AEC-Q200 standards
• Ideal for power supply circuits needing stable performance
• Effective in audio and video equipment for improved signal integrity
• Suitable for consumer electronics where space is at a premium
• Employed in industrial automation where reliability is critical
What is the significance of the low equivalent series resistance in this component?
A low equivalent series resistance (ESR) improves the efficiency of the circuit by reducing energy losses, resulting in better overall performance and heat dissipation during operation.
How does the high-temperature rating benefit specific applications?
The Ability to operate at temperatures up to +105 °C makes this component suitable for environments where heat is a concern, ensuring reliable performance without failure in high-demand applications.
What types of circuits are suitable for a polarised capacitor?
Polarised capacitors are typically used in DC circuits, where correct orientation is essential, thus providing stable and consistent functionality in varied electronic applications.
