Panasonic 100 μF Surface Mount Polymer Capacitor, 16 V | 16SVPT100M
1 ₫
Điện thoại/ Zalo tư vấn: 0921.811.784
* Chất lượng: Mới 100%
* Bảo hành: Chính hãng
* Chứng từ : CO/CQ, hóa đơn VAT
Đã bán: 3 pcs
Mfr. Part No: 16SVPT100M
Đánh giá: ⭐⭐⭐⭐⭐
Specifications
| Attribute | Value |
|---|---|
| Brand | Panasonic |
| Product Type | Polymer Capacitor |
| Technology | Polymer |
| Capacitance | 100μF |
| Voltage | 16 V |
| Mount Type | Surface Mount |
| Package/Case | 1000 |
| Polarity | Polar |
| Lead Pitch | 2.1mm |
| Tolerance | ±20 % |
| Maximum Operating Temperature | 105°C |
| Dimensions | 6.3 (Dia) x 6.6 mm |
| Series | SVPT |
| Length | 6.4mm |
| Depth | 6.6mm |
| Height | 6.6mm |
| Electrolyte Type | Solid |
| Automotive Standard | No |
| Lifetime | 20000 h |
| Diameter | 6.3 mm |
| Leakage Current | 300μA |
| Ripple Current | 2490mA |
| Minimum Operating Temperature | -55°C |
| Dissipation Factor | 12% |
Product Details
The Panasonic 100μF OS-CON SVP electrolytic aluminium capacitor construction with a high conductive polymer. It has excellent noise reduction capability and long life span. The capacitor used in PCs, motor drivers, measuring instruments, power supplies, security cameras and inverters.
Low ESR is (15 mO max.)
Large capacitance is (560 μF max.)
Rated voltage range is 2.5 V to 16 V
